Motorola PMNN4846A Battery for WM800 Wireless Speaker Microphone

The Motorola PMNN4846A is an original Motorola 2150mAh lithium-ion replacement battery designed specifically for the WM800 wireless remote speaker microphone. It provides dependable portable power for PMMN4156- and PMMN4158-series WM800 microphones used with compatible Motorola APX communication systems.

With an IP68 environmental rating and UL Division 2 compliance, the PMNN4846A is designed for public safety, utility, industrial and other demanding field applications. It is an excellent choice as either a direct replacement for a worn WM800 battery or a fully charged spare for extended shifts.

The PMNN4846A includes a swivel clip with D-ring, allowing the WM800 microphone to be securely attached to a uniform, jacket, vest or other approved carrying location.

PMNN4846A Features and Benefits

• Genuine Motorola OEM battery
• 2,150mAh rated capacity
• Rechargeable lithium-ion chemistry
• Designed specifically for the Motorola WM800 wireless RSM
• IP68-rated protection against dust and water
• UL Division 2 compliant
• User-replaceable design
• Includes swivel clip with D-ring
• Suitable as a primary or spare WM800 battery
• Supports quick battery changes between shifts
• Compatible with Motorola WM800 charging equipment

PMNN4846A Specifications

Important Compatibility Information

The PMNN4846A is a speaker-microphone battery—not a two-way radio battery. It attaches to and powers the WM800 wireless microphone. It does not mount directly onto an APX radio.

When the WM800 microphone has the required radio firmware and programming, it can be used with supported equipment from radio families such as:

• Motorola APX NEXT
• Motorola APX N70
• Motorola APX N50
• Motorola APX N30
• Select Motorola APX portable radios
• Select Motorola APX mobile radios
• Motorola SRX 2200 configurations

Radio compatibility is determined by the WM800 microphone, radio hardware, Bluetooth support, firmware and agency programming. The PMNN4846A’s direct physical compatibility is with the WM800 microphone itself.

Built for Demanding Environments

The PMNN4846A carries an IP68 rating, matching the WM800’s emphasis on rugged public-safety operation. This rating provides protection from dust and water exposure under Motorola’s specified testing conditions.

Its UL Division 2 compliance supports properly approved hazardous-location configurations where flammable gases, vapors or liquids are not normally present in ignitable concentrations but could appear under abnormal conditions.

PMNN4846A Charging Options

The PMNN4846A can be charged while installed on compatible WM800 equipment using approved charging accessories. The WM800 supports USB-C charging, while Motorola also offers a compatible dual-position desktop charging solution.

The Motorola PMPN4653A desktop charging tray can charge a WM800 microphone and a spare PMNN4846A battery, helping agencies prepare two power sources for the next shift.

For reliable operation, use only a charger specifically listed for the Motorola WM800 and PMNN4846A battery.

Why Keep a Spare PMNN4846A Battery?

Wireless speaker microphones require their own power source. If the WM800 battery becomes depleted, the radio may remain operational, but the user can lose convenient wireless access to the microphone’s speaker, push-to-talk and emergency controls.

Keeping a charged PMNN4846A available provides several advantages:

• Reduces WM800 downtime
• Enables fast field battery replacement
• Supports back-to-back shifts
• Simplifies fleet battery rotation
• Provides backup power during emergencies
• Avoids waiting for the microphone to recharge

Battery runtime varies according to transmit activity, received-audio volume, Bluetooth conditions, temperature, battery age and frequency of control use.

Frequently Asked Questions

What does the PMNN4846A fit?

The Motorola PMNN4846A fits the Motorola WM800 wireless remote speaker microphone, including PMMN4156- and PMMN4158-series models.

Does the PMNN4846A fit directly on an APX radio?

No. This battery powers the WM800 wireless speaker microphone. It is not a replacement battery for an APX portable radio.

Is the PMNN4846A compatible with the PMMN4158B?

Yes. The PMNN4846A is the correct removable battery for the Motorola PMMN4158B WM800 wireless speaker microphone.

Does it also fit the PMMN4158C?

Yes. The current PMMN4158C WM800 revision uses the PMNN4846A battery.

What is the capacity of the PMNN4846A?

The PMNN4846A has a rated capacity of 2,150mAh.

Is the PMNN4846A waterproof?

It is IP68 rated for dust and water protection under Motorola’s specified test conditions. All covers and components must be installed correctly to maintain environmental protection.

Is the PMNN4846A hazardous-location approved?

The battery is listed as UL Division 2 compliant. Verify approval of the complete radio and accessory configuration before use in a classified hazardous location.

Does the PMNN4846A include a clip?

Yes. Motorola lists the PMNN4846A as including a swivel clip with D-ring.

Order the Motorola PMNN4846A WM800 Battery

Restore dependable wireless microphone performance with the Motorola PMNN4846A 2150mAh lithium-ion battery. Its rugged IP68 construction, UL Division 2 compliance and user-replaceable design make it an ideal primary or spare battery for compatible Motorola WM800 wireless speaker microphones.

Before ordering, verify that your speaker microphone is a PMMN4156- or PMMN4158-series WM800 model.
